Features
- DC input range of 85-180 VDC
- Multi Output Power Supply
- Overvoltage and Short circuit protection
- Fan Cooled
Frequently purchased with this item
Product Overview
This is a specially designed Low Voltage Low Energy (LVLE) power supply module which converts higher DC input voltage into lower required DC voltages. LVLE2 provides regulated DC power to the mobile x-ray system and communicates with an external controller via I2C communication. The power supply accepts 85-180 VDC input and provide nine lower DC outputs which includes seven +24 VDC, a +48 VDC and a 12 VDC. These outputs are connected to variant system parts for different purposes. This unit is fully protected against overload, over voltage and short circuit or over current. LVLE2 can be operated under the different operation modes Latch-off mode, normal mode, testing mode, and shutdown mode. This power supply can be used with GE's XR Brivo XR285amx, Optima XR220 and Optima XR240 X-Ray Systems. 5192958-2-H
Additional Features
- Wide operating temperature
- Low output ripple
- High efficiency
- Compact Size
- RoHS Compliant
